Description
Pan Details
- Height: 420mm
- Width: 374mm
- Projection: 540mm
- Brand: Grohe
- Range: Euro Ceramic
- Type: Wall hung WC pan
- Material: Vitreous china
- Colour: White
- Supplied with WC seat with quick release action and Soft Close feature
Frame Details
- Height: 1135mm
- Width: 500mm
- Brand: Grohe
- Steel frame for dry lining fixed object connections
- Fastening material with quick adjustment and height safety device
- 2 WC holding bolts
- Ceramic fixing Screw spacing 180/230 mm
- Drain elbow Ø 90 mm
- depth adjustable
- reducer Ø 90/110 mm
- inlet and outlet
- cistern GD 2, 6-9l
- factory setting 6l and 3l
- pneumatic drain valve with two functions:
- Set or start & stop
- water connection from left / right / rear or top Faucet group
Flush Plate Details
- Width: 156mm
- Height: 197mm
- Depth: 10mm
- Brand: Grohe
- Range: Skate Cosmopolitan
- Type: WC Wall Flush Plate
- GROHE StarLight chrome finish
- GROHE EcoJoy technology for less water and perfect flow
- Material: ABS
- For dual flush or start & stop actuation
- For vertical or horizontal installation
- For pneumatic drop valve AV1
5 Year Guarantee
Picture for illustrative purposes only
All measurements are approximate
Comprises
Euro Ceramic Compact Wall Hung Pan
Euro Ceramic Soft Close Seat
Skate Cosmopolitan Flush Plate Chrome
Solido Frame 1.13m / 3/6L Cistern
Sound Insulation Set
